Value of Gd-EOB-DTPA-enhanced MRI in diagnosis of hepatocellular carcinoma
-
摘要:
目的探讨钆塞酸二钠（Gd-EOB-DTPA）MRI诊断肝细胞癌（HCC）的临床价值。方法选择2016年10月-2017年4月于沈阳军区总医院就诊的40例肝硬化或疑似HCC患者,收集患者的Gd-EOB-DTPA增强MRI动态三期（动脉期、门静脉期、延迟期）及肝胆期（延迟20 min）和弥散加权成像（DWI）（b=50、400、1000 s/mm2）资料。2位医师协商一致根据有、无肝胆期图像分别作出诊断及信心评分。以术后病理或临床诊断为标准评价HCC诊断准确率。计量资料采用t检验分析,计数资料采用χ2检验。结果 40例患者共检出42个HCC病灶和37个肝硬化结节。HCC和肝硬化结节在肝胆期和DWI序列中信号强度差异有统计学意义（χ2值分别为64.503、67.855,P值均<0.001）。HCC和肝硬化结节在b=400 s/mm2和b=1000 s/mm2DWI序列时的表观扩散系数比较差异均有统计学意义（t值分别为62.75、75.36,P值均<0.001）。诊断医师通过Gd-EOB-DTPA增强动态三期以及动态四期（含肝胆期）两组图...
Abstract:Objective To investigate the value of Gd-EOB-DTPA-enhanced MRI in the diagnosis of hepatocellular carcinoma ( HCC) .Methods A total of 40 patients with liver cirrhosis or suspected HCC who visited General Hospital of Shenyang Military Area Command from October 2016 to April 2017 were enrolled, and the data on three dynamic phases of Gd-EOB-DTPA-enhanced MRI ( arterial phase, portal venous phase, and delayed phase) , hepatobiliary phase ( delayed for 20 minutes) , and diffusion-weighted imaging ( DWI) ( b = 50, 400, and 1000 s/mm2) were collected. Two radiologists made a diagnosis and gave diagnostic confidence scores based on the presence or absence of hepatobiliary phase images. Postoperative pathology or clinical diagnosis was used as the criteria for assessing the diagnostic accuracy of HCC. The t-test was used for comparison of continuous data, and the chi-square test was used for comparison of categorical data.Results A total of 42 HCC lesions and 37 cirrhotic nodules were detected. There were significant differences between HCC lesions and cirrhotic nodules in signal intensity on hepatobiliary phase and DWI ( χ2= 64. 503 and 67. 855, both P < 0. 001) , as well as the apparent diffusion coefficient when the b-values of DWI were 400 s/mm2 and 1000 s/mm2 ( t = 62. 75 and 75. 36, both P < 0. 001) . There was a significant difference in diagnostic confidence score given by the radiologists between the images of three dynamic phases of Gd-EOB-DTPA-enhanced MRI and those of four dynamic phases ( including hepatobiliary phase) ( 3. 260 ± 0. 521 vs 4. 620 ± 0. 661, t = 10. 67, P <0. 001) . With postoperative pathology and clinical diagnosis as criteria, the images of three dynamic phases of Gd-EOB-DTPA-enhanced MRI had a significantly higher diagnostic accuracy for HCC than those of four dynamic phases ( including hepatobiliary phase) [76. 19% ( 32/42) vs 95. 24% ( 40/42) , χ2= 6. 222, P = 0. 013]. Conclusion Gd-EOB-DTPA-enhanced MRI may improve diagnostic accuracy and confidence for HCC and has an important clinical value.
-
[1]CHEN WQ, ZHENG RS, BAADE PD, et al.Cancer statistics in China, 2015[J].CA Cancer J Clin, 2016, 66 (2) :115-132. [2]National Health and Family Planning Commission of the People's Republic of China.Diagnosis, management, and treatment of hepatocellular carcinoma (V2017) [J].J Clin Hepatol, 2017, 33 (8) :114-126. (in Chinese) 中华人民共和国国家卫生和计划生育委员会.原发性肝癌诊疗规范 (2017年版) [J].临床肝胆病杂志, 2017, 33 (8) :114-126. [3]Abdominal Study Group, Chinese Society of Radiolog, Chinese Medical Association.Expert consensus on clinical application of hepatobiliary-specific MRI contrast agent Gd-EOB-DTPA[J].J Clin Hepatol, 2016, 32 (12) :2236-2241. (in Chinese) 中华医学会放射学分会腹部学组.肝胆特异性MRI对比剂钆塞酸二钠临床应用专家共识[J].临床肝胆病杂志, 2016, 32 (12) :2236-2241. [4]KIERANS AS, KANG SK, ROSENKRANTZ AB.The diagnostic performance of dynamic contrast enhanced MR imaging for detection of small hepatocellular carcinoma measuring up to 2 cm:a meta analysis[J].Radiology, 2016, 278 (1) :82-94. [5]CHEN CZ, RAO SX, DING Y, et al.Hepatocellular carcinoma 20 mm or smaller in cirrhosis patients:early magnetic resonance enhancement by gadoxetic acid compared with gadopentetate dimeglumine[J].Hepatol Int, 2014, 8:104-111. [6]ZENG MS, YE HY, GUO L, et al.Gd-EOB-DTPA-enhanced magnetic resonance imaging for focal liver lesions in Chinese patients:a multicenter, open-label, phaseⅢstudy[J].Hepatobiliary Pancreat Dis Int, 2013, 12 (6) :607-616. [7]American College of Radiology.Liver Imaging Reporting and Data System version, 2014[EB/OL].http://www.acr.org/qualitysafety/resources/LIRADS, 2015-12-07. [8]ZHENG KG, XU DS, SHEN JX.Helical CT appearance of hypovascular small hepatocellular carcinoma with pathologic correlation[J].Chin J Radiol, 2003, 37 (10) :930-934. (in Chinese) 郑可国, 许达生, 沈静娴.少血供小肝癌的螺旋CT表现并与病理对照[J].中华放射学杂志, 2003, 37 (10) :930-934. [9]DING Y, ZENG MS.Clinical application of liver specific contrast agent Gd+-EOB-DTPA in progression assessment and early diagnosis of hepatocellular carcinoma[J].J Clin Hepatol, 2013, 29 (10) :736-739. (in Chinese) 丁莺, 曾蒙苏.普美显在肝硬化结节多步癌变及肝细胞癌早期诊断中的应用[J].临床肝胆病杂志, 2013, 29 (10) :736-739. [10]KOGITA S, IMAI Y, OKADA M, et al.Gd-EOB-DTPA-enhanced magnetic resonance images of hepatocellular carcinoma:correlation with histological grading and portal blood flow[J].Eur Radio, 2010, 20 (10) :2405-2413. [11]XIA LF, YAN RF, YAN HL, et al.The value of multi-b-value diffusion weighted imaging in the diagnosis of focal hepatic lesions[J].Chin Comput Med Imag, 2016, 22 (2) :138-142. (in Chinese) 夏林峰, 闫瑞芳, 闫海龙, 等.多b值DWI对肝脏局灶性占位性病变的诊断价值研究[J].中国医学计算机成像杂志, 2016, 22 (2) :138-142. [12]FEDERAU C, MAEDER P, O'BRIEN K, et al.Quantitative measurement of brain perfusion with intravoxel incoherent motion MR imaging[J].Radiology, 2012, 265 (2) :874-881. [13]FAN G, ZANG P, JING F, et al.Usefulness of diffusion perfusion weighted MRI in C6 rat gliomas:correlation with histopathology[J].Aca Radiol, 2005, 12 (5) :640-651. [14]ICHIKAWA T, HARADOME H, HACHIVA J, et al.Diffusionweighted MR imaging with a single-shot echoplanar sequence:detection and characterization of focal hepatic lesions[J].AJR Am J Roentgenol, 1998, 170 (2) :397-402. -
