Diagnostic efficacy of shear wave elastography in evaluating chronic hepatitis B liver fibrosis and related influencing factors
-
摘要:
目的探讨剪切波弹性成像(SWE)评估慢性乙型肝炎(CHB)肝纤维化的诊断效能及影响因素。方法收集2016年1月-2017年9月于中国医科大学附属盛京医院就诊的CHB患者147例,所有患者均行剪切波弹性成像(SWE)检查,SWE检查之后1周内均进行肝穿刺活组织检查。同时收集患者的一般资料及血清学检测结果。不服从正态分布的计量资料组间比较采用MannWhitney U检验;计数资料组间比较采用χ2检验。绘制受试者工作特征曲线(ROC曲线)评估诊断效能,logistic回归模型分析影响SWE诊断肝纤维化分期准确度的因素。结果以肝组织学诊断肝纤维化分期为标准,SWE诊断肝纤维化≥F1期、≥F2期、≥F3期和≥F4期的ROC曲线下面积分别为0. 824、0. 880、0. 914和0. 986,最佳诊断界值分别为6. 1 k Pa、7. 0 k Pa、8. 1 kPa、10. 0 k Pa,敏感度分别为91. 0%、91. 7%、87. 0%、88. 9%,特异度分别为66. 0%、82. 8%、66. 0%、94. 9%,阳性预测值分别为85. 0%、78. 6%、48....
Abstract:Objective To investigate the diagnostic efficiency of shear wave elastography ( SWE) in evaluating chronic hepatitis B ( CHB) liver fibrosis and related influencing factors. Methods A total of 147 CHB patients who visited Shengjing Hospital of China Medical University from January 2016 to September 2017 were enrolled. SWE was performed for all patients, and liver biopsy was performed within one week after SWE. General information and serological test results of the patients were collected. The Mann-Whitney U test was used for comparison of non-normally distributed continuous data; the chi-square test was used for comparison of categorical data between groups.The receiver operating characteristic ( ROC) curve was plotted to evaluate diagnostic efficiency, and the logistic regression model was used to determine the factors associated with the accuracy of SWE in assessing liver fibrosis stage. Results With liver fibrosis stage determined by liver histology as the standard, the areas under the ROC curve of SWE in the diagnosis of ≥F1, ≥F2, ≥F3, and ≥F4 liver fibrosis were0. 824, 0. 880, 0. 914, and 0. 986, respectively, with sensitivities of 91. 0%, 91. 7%, 87. 0%, and 88. 9%, respectively and specificities of 66. 0%, 82. 8%, 66. 0%, and 94. 9%, respectively, at the optimal cut-off values of 6. 1 kPa, 7. 0 k Pa, 8. 1 kPa, and 10. 0 k Pa, respectively. The positive predictive values were 85. 0%, 78. 6%, 48. 3%, and 53. 3%, respectively, and the negative predictive values were 77. 5%, 93. 5%, 97. 2%, and 99. 2%, respectively. According to the results of liver biopsy, of all 147 patients, 94 had an accurate diagnosis based on SWE, while 53 had an inaccurate diagnosis; there were significant differences between these two groups in alanine aminotransferase, aspartate aminotransferase, and liver inflammation grade ( Z =-4. 211、-4. 649、-3. 513, all P < 0. 01) . Liver inflammation grade ( odds ratio [OR]= 0. 552, 95% confidence interval [CI]: 0. 317-0. 963, P = 0. 028) was an independent influencing factor for the diagnostic accuracy of SWE, and it had a significant effect on SWE in diagnosing liver fibrosis in the case of stage F0 liver fibrosis ( OR= 1. 809, 95% CI: 2. 305-51. 195) and stage F2 liver fibrosis ( OR = 1. 345, 95% CI: 1. 037-13. 647) . Conclusion Liver stiffness measured by SWE has good diagnostic efficacy in assessing liver fibrosis stage, and the accuracy of liver fibrosis stage assessment is affected by liver inflammation stage.
-
Key words:
- hepatitis B, chronic /
- liver cirrhosis /
- elasticity imaging techniques /
- diagnosis /
- risk factors
-
[1] PELLICORO A, RAMACHANDRAN P, LREDALE JP, et al. Liver fibrosis and repair:Immune regulation of wound healing in a solid organ[J]. Nat Rev Immunol, 2014, 14 (3) :181-194. [2] FRIEDMAN SL, BANSAL MB. Reversal of hepatic fibrosis—fact or fantasy?[J]. Hepatology, 2006, 43 (S1) :s82-s88. [3] van DER POORTEN D, KWOK A, LAM T, et al. Twenty-year audit of percutaneous liver biopsy in a major Australian teaching hospital[J]. Intern Med J, 2006, 36 (11) :692-699. [4] BRAVO AA, SHETH SG, CHOPRA S. Liver biopsy[J]. N Engl J Med, 2001, 344 (7) :495-500. [5] BEDOSSA P, DARGERE D, PARADIS V. Sampling variability of liver fibrosis in chronic hepatitis C[J]. Hepatology, 2003, 38 (6) :1449-1457. [6] PARK BK, PARK YN, AHN SH, et al. Long-term outcome of chronic hepatitis B based on histological grade and stage[J]. J Gastroenterol Hepatol, 2007, 22 (3) :383-388. [7] HAN XY, CHEN XJ, YAN ZQ, et al. Correlation among HBsAg and HBV DNA levels with liver fibrosis in patients with hepatitis B[J]. Int J Virol, 2016, 23 (1) :50-52. (in Chinese) 韩晓颖, 陈秀记, 闫泽强, 等.血清HBsAg与HBV DNA水平与乙肝患者肝纤维化程度的相关性分析[J].国际病毒学杂志, 2016, 23 (1) :50-52. [8] NIU M, DENG DY, LIYUN PF, et al. Value of MRE in diagnosis of stages of hepatic fibrosis:A Meta-analysis[J]. J Jilin Uiniv:Med Edit, 2017, 43 (4) :787-793. (in Chinese) 牛猛, 邓大勇, 李云鹏飞, 等.磁共振弹性成像对肝纤维化分级诊断价值的Meta分析[J].吉林大学学报:医学版, 2017, 43 (4) :787-793. [9] LEI JW, TAN BB, LI WB, et al. Value of transient elastography measured with FibroTouch in the diagnosis of liver fibrosis in chronic hepatitis patients with hepatocellular carcinoma[J]. Chin J Med Offic, 2017, 45 (9) :930-933. (in Chinese) 雷洁雯, 谭碧波, 李万斌, 等. FibroTouch瞬时弹性成像诊断慢性乙型肝炎合并肝癌患者肝纤维化程度应用研究[J].临床军医杂志, 2017, 45 (9) :930-933. [10] SARIN SK, KUMAR M, LAU GK, et al. Asian-Pacific clinical practice guidelines on the management of hepatitis B:A 2015 update[J]. Hepatol Int, 2016, 10 (1) :1-98. [11] Panel of Elastography Assessment of Liver Fibrosis, Study Group of Interventional Ultrasound, Society of Ultrasound in Medicine of Chinese Medical Association. Guidelines for clinical application of two-dimensional shearwave elastography in assessment of liver fibrosis in chronic hepatitis B[J]. J Clin Hepatol, 2018, 34 (2) :255-261. (in Chinese) 中华医学会超声医学分会介入超声学组弹性成像评估肝纤维化专家组.二维剪切波弹性成像评估慢性乙型肝炎肝纤维化临床应用指南[J].临床肝胆病杂志, 2018, 34 (2) :255-261. [12] Chinese Society of Hepatology and Chinese Society of Infectious Disease, Chinese Medical Association. The guideline of prevention and treatment for chronic hepatitis B:a 2015 update[J]. J Clin Hepatol, 2015, 31 (12) :1941-1960. (in Chinese) 中华医学会肝病学分会, 中华医学会感染病学分会.慢性乙型肝炎防治指南 (2015年更新版) [J].临床肝胆病杂志, 2015, 31 (12) :1941-1960. [13] CHANGTIAN LI, CHANGSHENG ZHANG, JUNLAI LI, et al. Diagnostic accuracy of real-time shear wave elastography for staging of liver fibrosis:A meta-analysis[J]. Med Sci Monit, 2016, 22:1349-1359. [14] JIANG T, TIAN G, ZHAO Q, et al. Diagnostic accuracy of 2D-shear wave elastography for liver fibrosis severity:A Meta-analysis[J].PLo S One, 2016, 11 (6) :e0157219. [15] HAN XM, ZHANG Z, WANG XM, et al. Analysis of influence factors on hepatic elasticity measurement with shear wave elastography[J/CD]. Chin J Med Ultrasound:Electronic Edition, 2014, 11 (12) :18-21. (in Chinese) 韩秀梅, 张震, 王学梅, 等.剪切波弹性成像技术测量肝脏弹性的影响因素分析[J/CD].中华医学超声杂志:电子版, 2014, 11 (12) :18-21. [16] HIROTOSHI E, HIDETSUGU S, MINA K, et al. Evaluation of liver fibrosis by transient elastography using acoustic radiation force impulse:Comparison with Fibroscan (?) [J]. J Gastroenterol, 2011, 46 (10) :1238-1248. 期刊类型引用(20)
1. 鲍春旭,马小萍,高文涛,邓燕龄,王红. 剪切波弹性成像联合肝脂肪变性指数对肥胖者中非酒精性脂肪肝患者疗效的评估. 宁夏医学杂志. 2024(03): 256-258 . 百度学术
2. 武岩岩,任秀东,王建红. 2D-SWE对自身免疫性肝病病人肝纤维化程度的诊断价值. 青岛大学学报(医学版). 2024(02): 284-287 . 百度学术
3. 宋军,倪璐佳,张涵玉,李兴肇. 超声造影联合剪切波弹性成像技术对肝脏良恶性肿瘤诊断价值的Meta分析. 临床肝胆病杂志. 2024(07): 1404-1410 . 本站查看
4. 秦文娟,邵孝,李可兴. SWE技术在慢性乙型肝炎肝纤维化评估中的应用价值. 罕少疾病杂志. 2024(08): 72-74 . 百度学术
5. 王雪鑫,李颖霞,姜利彬,周明霞,魏大鹏,张晓朋,温洪涛. 实时剪切波弹性成像对自身免疫性肝炎纤维化的诊断价值. 临床肝胆病杂志. 2023(01): 97-103 . 本站查看
6. 丁世兰,朱成诚,肖春华,李鸿,李永峰,丁捷,杨皖东. 剪切波弹性成像及血清学模型评估慢性肝病纤维化. 中国临床研究. 2023(01): 70-75 . 百度学术
7. 滕文汇,蓝天琦,白杨,李平,孙萌,连晓晗,王兆铂,刘春凤,邹辉. 超声新技术在肝脏良恶性病变中的应用研究进展. 中国当代医药. 2023(07): 54-57 . 百度学术
8. 李卉. 生化检验在乙型病毒性肝炎肝纤维化中的临床应用价值分析. 中国现代药物应用. 2023(05): 76-78 . 百度学术
9. 赵江洋. 病毒性肝炎肝纤维化采用实时剪切波弹性成像与常规超声的评估效果比较. 现代诊断与治疗. 2023(19): 2950-2953 . 百度学术
10. 陈杉杉,刘洋,王艺桦,陈颖,李鑫淼,张树华. 超声弹性模量联合FIB-4对乙肝肝硬化诊断价值分析. 医学研究杂志. 2022(04): 86-89 . 百度学术
11. 车艳玲,宋美琪,徐皓煊,汝童,曾华兰,梁国英,孙玉华,王星,宗立秋. 基于SWE技术评估三甲逍遥散治疗肝纤维化的临床观察. 中医药学报. 2021(02): 71-74 . 百度学术
12. 何自倩,周明姣,李永忠. 实时剪切波弹性成像在诊断乙肝病毒肝纤维化患者中的价值. 分子影像学杂志. 2021(01): 122-126 . 百度学术
13. 林洁莲,陈鑑强. 乙肝病毒载量与乙型肝炎患者肝功能转氨酶谱及肝弹性的相关性. 中国医学创新. 2021(27): 145-148 . 百度学术
14. 高洁,严惠芬,梅冬,唐春莲,余文惠. 超声多模态在肝血管瘤病诊断中的应用. 中国临床医学影像杂志. 2021(11): 812-816 . 百度学术
15. 李洁,杨晓青,齐素艳,王立美,冯苏. 二维实时剪切波弹性成像诊断慢性肝病肝纤维化的危险因素分析. 河北医药. 2021(23): 3578-3581 . 百度学术
16. 卢慧宇,孙娜,徐虹. 纽曼系统护理对慢性乙型肝炎肝纤维化患者负性情绪和生存质量的影响. 中西医结合护理(中英文). 2021(06): 163-165 . 百度学术
17. 张敏,张花. 组织结构声学定量技术无创评估慢性乙型肝炎肝纤维化的临床研究. 现代医药卫生. 2020(01): 1-4 . 百度学术
18. 朱卓琳,陈方红,黄岩花. 声速匹配组织量化技术对慢性乙型肝炎肝纤维化分期的初步效果观察. 中国现代医生. 2020(10): 136-139+144 . 百度学术
19. 刘磊,唐缨,张国英. 超声剪切波弹性成像技术在移植肝术后监测中的应用进展. 实用器官移植电子杂志. 2020(05): 409-412+328 . 百度学术
20. 郑悠,许永生,张旭霞,刘海峰,刘钊,雷军强. 肝纤维化的影像学诊断现状. 临床肝胆病杂志. 2019(08): 1838-1841 . 本站查看
其他类型引用(8)
-
